// EW-101

Tabletop Wiring Training System

The compact, tabletop EW-101 Electrical Wiring Training System allows for hands-on student lab activities in wiring residential, commercial/industrial, HVAC, and low-voltage systems (fire alarm, security system, etc) circuits.

The double-sided, hands-on training system gives students safe and approachable access to wire various circuits and devices commonly found in real world settings.

Description

The EW-101 Industrial Wiring System is a complete hands-on solution for teaching the fundamental concepts of residential, commercial and industrial wiring. This system can be ordered in either a single-phase 240/120 or three-phase 208/120 configuration.

Each configuration can also include any 2 Training Panels listed below:

Residential Wiring Focus (EW-101-1R)

  • 12 Circuit Load Center
  • 1-Pole Breakers
  • 2-Pole Breakers
  • GFCI Breakers
  • Single-Pole Switches
  • 3-Way Switches
  • 4-Way Switches
  • Duplex Receptacles
  • GFCI Receptacles
  • Lighting Fixtures
  • Smoke Detectors

Industrial Wiring Focus (EW-101-2I)

  • Pushbuttons, Indicator Lights, Control Transformer, Motor, Motor Starter, Relay
  • Locking Disconnect
  • Non-Reversing Starter
  • E-Stop Pushbutton
  • Selector Switch
  • Indicator Lights
  • 3-Pole Main Breaker
  • Timing Module
  • HVAC Electrical Wiring Focus (EW-101-3H)
  • 120/240 Power Entry
  • Integrated Power Bus
  • Locking Disconnect

HVAC Electrical Wiring Components

  • (1x) Pull-Out Disconnect
  • (1x) Transformer
  • (1x) 24Vac Relay
  • (1x) 120Vac Heat Sequencer
  • (2x) 120Vac Relays
  • (2x) 24Vac Relays
  • (1) 24Vac Contactor
  • (3) Indicator Lights
  • Hermetic Compressor Add-On Unit* (Optional)
