Residential Wiring

RW-201

The RW-201 Residential Wiring Training System provides participants with a compact mobile framing system allowing for installation and connection of various residential electrical circuits and devices in a reusable format. This system gives access to real world electrical components simulating actual residential installations in a realistic house frame model. The mobile frame includes a floor, (3) stud wall sections and an optional roof framing section. The system’s unique mobile industrial frame allows for easily transport – fitting through most interior classroom doors – and folding legs allow for quick and easy storage when not being used.

From Our Partners at Innotek

DESCRIPTION

The RW-200 Residential Wiring Training System gives students access to practical hands-on training exercises they are most likely to see in future careers.

Learning Outcomes Include:

Electrical Drawings and Symbols
Conductor Types and Sizing
Service Entrance Equipment
Branch and Feeder Circuits
Overcurrent Protection
Wiring Methods
Multi-Wire Circuits
Lighting
Smoke Detectors
Door Signals and Chimes
Troubleshooting

System Includes:

Mobile Frame
Wall and Floor Framing
Service Entrance Equipment
Load Center and Breakers
Device Boxes
Wiring Devices
Lighting Loads
Smoke Detectors
Door Signals and Chimes
Ceiling fan included with roof framing add-on*

Solar Installation Add-on:

Mobile Pole with Locking Casters
Solar Panel and Hardware
Battery and Charging System
Inverter for AC Loads
Light Source for Indoor Operation
Mounting Hardware for Installation on Roof of RW-201 System
