The first step to securing funding is building a plan for your program. Let us help you get started.
The EMCOMAT 14D is the smallest machine in the EMCOMAT series. The EMCOMAT 14D is a lathe for the most demanding requirements: infinitely-variable speed control, constant cutting speed and an impressive 7.5 kW of drive power (40% duty cycle). This small yet powerful machine is mainly used where highly accurate work needs to be carried out in a small space, such as in optical, electrical and automobile workshops, laboratories and even Formula 1.
| Travel in X/Y/Z | 135 / – / 590 mm |
| Distance between centers | 650 mm |
| Distance above centers | 140 mm |
| Max. speed | 4000 U/min |
| Spindle nose | Größe 4 (DIN 55029) |
| Max. drive power | 7,5 kW |
| Quill diameter | 30 mm |
| Inner cone | MK 2 |
| Quill travel | 80 mm |
| Dimensions (LxWxH) | 1280 x 1480 x 730 mm |
| Machine weight | 420 kg |
