EMCOMAT E-400

You will find the right machine for your production needs in our EMCOMAT e-series, which offers a selection of distances between centers ranging from 2000 to 6000 mm. even the most difficult machining tasks become child’s play. Thanks to solid machine construction and components of the highest quality and stability. ZF drive, Siemens drive systems and backlash-free circulating-ball spindles assure optimal quiet running and high precision, even for heavy-duty metal cutting.

From Our Partners at

DESCRIPTION

EQUIPMENT

Various manual and automatic tool turret systemsFully covered work area with sliding machine doorsTeach-In control Fagor 8055 TSiemens drive package with AC motorsMachine stand with large coolant tank and chip basin Carriage drives

TECHNICAL DATA

WORK AREA
Travel in X/Y/Z 520/1500-6000 mm
Distance between centers 1500-6000 mm
Distance above centers 430 mm
Feed force in X/Y/Z 1400/1400 daN
MAIN SPINDLE
Max. speed 1200 rpm
Max. drive power 33 kW
TAILSTOCK
Quill travel 220 mm
GENERAL DATA
Dimensions (LxWxH) (3060 + distance between centers) x 2470 x 2070 mm
Machine weight 9500 – 10700 kg

HIGHLIGHTS

  • ZF gears with two steps
  • High class Siemens drive systems
  • Circulating ball screws free of play for quiet running and high precision
  • Robust, cast-iron machine bed with strong ribbings
  • Various machine lengths
  • Optimal accessibility of the work area
